Greenheck Fan Corp., based in Schofield, Wis., updated the company’s plug-in, eCAPS Bridge, for Autodesk Revit software and Greenheck’s products.
The plug-in allows users to select and schedule Greenheck’s HVAC equipment without leaving Revit environments. The updated version of eCAPS Bridge allows access to additional Revit content and more functionality.
Dedicated outdoor air systems (DOAS) LOD 300 content can now be selected by performance. DOAS schedule and parameter mapping capabilities have been added. Parameter mapping can now be applied to energy recovery ventilator (ERV) and DOAS content from Greenheck’s CAPS computer aided product selection program. Basic LOD 200 configuration options for the SQ direct drive square centrifugal inline fans, BSQ belt drive square centrifugal inline fans, and USF utility set fans including USF filtering options can now be accessed via the select by model window.
A damper schedule is now available for LOD 200 Damper content. In addition, users can now rename schedule headers and save these changes to their schedule layout setting for future use.
Global clearance on/off buttons allow users to adjust service clearances on all Greenheck content placed in a Revit project.
The eCAPS Bridge to Revit plug-in automates the schedule creation process. Product selections can be made by performance, model, and accessing saved eCAPS jobs. Multiple product schedules can then be configured and created. Many product types including fans, louvers, dedicated outdoor air units, and pre-conditioners along with hundreds of Revit families are available.
